Introduction:
Glass fiber filter paper is made of super fine glass fiber as the filter layer, synthetic fiber or natural fiber as a protective layer composite on the two sides, to improve the mechanical strength, and solves the secondary pollution problem caused by super fine glass fiber which is easy to fall off. It has high filtration efficiency, stable physical and chemical properties, which is a new type of filter material.
Characteristics:
Isotropic, uniform pore size distribution, quantitative small deviation, heat resistant, flame retardant, waterproof, assimilative capacity for wastes, etc.
Application:
It can be used for the production of box type filter, folded filter, effectively filter the gas, inorganic solvent,oil, etc.
Used for filtering solid impurity in oil, water, also dust and all kinds of sol particles in the air. Widely used for filtering aviation oil, shipbuilding and heavy machinery hydraulic oil, nuclear power plant water, oil-field flooding, air compressor, etc.
Physical Index
Model | GT-01 | GT-03 | GT-05 | GT-10 | GT-15 | GT-20 | GT-30 |
Filtering Precision(µm) | 1 | 3 | 5 | 10 | 15 | 20 | 30 |
Thickness(mm) | 0.45±0.05 | ||||||
Tensile Strength (kg/15 mm) | >2 | ||||||
Bursting Strength (Mpa) | >0.2 | ||||||
Width(mm) | 600--1000 |
